The TCP8301.I OnLine profilometer

Technical parameters:

  • Width measurement range of up to 1,000 mm (standards are 550, 750, and 1,000 mm)
  • Thickness measurement range of up to 60 mm
  • Width precision < ±200 µm (3 sigma)
  • Thickness precision < ±20 µm (3 sigma)
  • Frequency of 20 measurements per second

Suitable for:

  • tread
  • sidewall (1 or 2 profiles)
  • inner liner
  • rubber strips (max. 18 strips)

Versions:

  • online profilometer for the warm zone
  • online profilometer for the cool zone

Options:

  • combining with profile length measurement
  • combining with a continuous scale
  • combining with profile defect detection
  • calibration unit
  • profile temperature measurement
  • auto-calibration during measurement

Benefits:

  • Contact-free measurement of profile geometry
  • Online measuring system for quality control
  • This system can be used for controlling an extrusion head/line
  • This system can be used for automatic profile sorting
  • Unique automatic calibration throughout the whole measurement range
  • Automatic temperature compensation
